Запчасти Komatsu PC290LC-10 P- КОНЕЧНАЯ ПЕРЕДАЧА (/) МОТОР ХОДА - ВНУТР. ЧАСТИ НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

207-27-00471

FINAL DRIVE ASSEMBLY

|$1

708-8H-00351

MOTOR, TRAVEL

|$2

708-8H-04712

CASE ASSEMBLY

1

NSS

CASE, MOTOR

2

NSS

PLUG

|$5

708-8H-04721

COVER ASSEMBLY

3

NSS

COVER, END

4

NSS

SPOOL

5

NSS

SPOOL

6

NSS

PLUG

7

NSS

SPRING

8

NSS

PLUG

9

706-75-42820

PIN, DOWEL

10

708-8H-11530

PLUG

11

07002-11423

O-RING

12

20B-27-11210

BLEEDER

13

706-73-72420

VALVE

14

706-73-72440

SPRING

15

708-8H-36150

PLUG

16

07000-12018

O-RING

17

708-8H-36160

RING, BACK-UP

18

706-78-71160

PISTON

19

708-8H-36121

SPRING

20

708-8H-16141

PLUG

21

07002-13634

O-RING

22

04260-00793

BALL

23

706-8E-14110

PLUG

24

07002-11023

O-RING

25

708-8E-16180

VALVE

26

708-8E-16160

PLUG

27

07002-11023

O-RING

28

708-8H-31210

O-RING

29

07000-12012

O-RING

30

04020-01228

PIN, DOWEL

31

01252-62055

BOLT

32

01252-62095

BOLT
