Запчасти Komatsu PC290LC-10 N- МЕХАНИЗМ ПОВОРОТА ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

22U-26-21280

RING

2

07042-00312

PLUG, TAPER

3

206-26-73310

CASE

4

206-26-73150

BEARING

5

206-26-73160

BEARING

6

206-26-73210

SHAFT

7

206-26-73140

SPACER

8

07000-15100

O-RING

9

20Y-26-22420

SEAL

10

206-26-73120

COVER

11

01010-81040

BOLT

12

01643-31032

WASHER

13

07000-15310

O-RING

14

206-26-71480

CARRIER

15

206-26-71440

GEAR

16

22U-26-21320

BEARING

17

206-26-71520

WASHER, THRUST

18

206-26-71510

PIN

19

20Y-26-21330

PIN

20

20Y-26-21240

PLATE

21

112-32-11211

BOLT

22

206-26-71452

GEAR

23

20K-22-11190

O-RING

24

01010-81440

BOLT

25

01643-31445

WASHER

26

206-26-71430

GEAR

27

04260-01270

BALL

28

206-26-71471

CARRIER

29

206-26-71420

GEAR

30

20Y-27-22210

BEARING

31

22U-26-21230

WASHER, THRUST

32

206-26-71210

PIN

33

04064-03515

RING, FOR SHAFT SIDE

34

206-26-71350

HOLDER

35

206-26-71410

GEAR

36

206-26-71341

PLATE
