Запчасти Komatsu PC290LC-10 H- ОСНОВН. ПОРШЕНЬ НАСОС ВНУТР. ЧАСТИ (/) ГИДРАВЛИКА

|$0

708-2G-00310

PUMP ASSEMBLY

|$1

708-2G-01310

PUMP SUBASSEMBLY

1

708-2G-12610

SHAFT, FRONT .

2

708-2L-42250

BEARING

3

708-2E-05040

WASHER KIT

|$5

NSS

WASHER, T= 3.1 MM

|$6

NSS

WASHER, T= 3.0 MM

|$7

NSS

WASHER, T= 2.9 MM

|$8

NSS

WASHER, T= 2.8 MM

4

708-25-12790

RING, SNAP

5

708-2L-32460

SEAL, OIL

6

708-2L-22160

SPACER

7

04065-06825

RING, SNAP, FOR HOLE SIDE

|$13

708-2G-04640

BLOCK ASSEMBLY, FRONT

8

NSS

BLOCK, CYLINDER

9

NSS

PLATE, VALVE

10

708-18-13230

PIN

11

04065-05820

RING, SNAP

12

708-2L-43130

SEAT

13

708-2G-13760

SPRING

14

708-2H-23141

SEAT

15

708-2G-13740

GUIDE, RETAINER

16

708-2L-43360

PIN

17

708-2G-13750

RETAINER, SHOE

18

708-2L-43311

PISTON SUBASSEMBLY

|$25

708-2G-04660

CRADLE ASSEMBLY

19

NSS

CRADLE

20

NSS

CAM, ROCKER

21

04020-01228

PIN

22

01252-61025

BOLT, HEXAGON SOCKET HEAD
