Запчасти Komatsu PC290LC-10 H- ГИДР. БАК. ГИДРАВЛИКА

1

206-60-35110

TANK

2

203-60-31100

ELBOW ASSEMBLY

3

203-60-31160

TUBE

4

02781-00628

UNION

5

02896-11018

O-RING

6

07002-12434

O-RING

7

02782-10524

ELBOW

8

02896-11015

O-RING

9

07002-12434

O-RING

10

02782-10315

ELBOW

11

02896-11009

O-RING

12

07002-12034

O-RING

13

07040-12412

PLUG

14

07002-12434

O-RING

15

07040-12012

PLUG

16

07002-12034

O-RING

17

207-60-71182

ELEMENT

18

20Y-60-31140

STRAINER

19

20Y-60-31131

VALVE ASSEMBLY

20

20Y-60-21240

SPRING

21

2A5-60-11150

COVER

22

07000-15195

O-RING

23

01010-81230

BOLT

24

01643-31232

WASHER

|$24

2A5-60-11121

STRAINER ASSEMBLY

25

2A5-60-11130

ROD ASSEMBLY

26

20Y-60-21320

HOLDER

27

12R-60-11230

SPRING

28

22B-60-11160

STRAINER

29

2A5-60-11141

COVER

30

07000-15160

O-RING

31

01010-81230

BOLT

32

01643-31232

WASHER

33

22U-60-31120

CAP ASSEMBLY

34

20Y-60-21470

ELEMENT

35

208-60-71181

FILLER NECK

36

20Y-60-21340

GASKET

37

01252-A0516

BOLT, HEXAGON SOCKET HEAD

38

01601-20513

WASHER, SPRING

39

07285-00220

CLIP, HOSE

40

07261-21414

HOSE

41

04434-52312

CLIP

42

01010-81225

BOLT

43

01643-31232

WASHER

44

205-00-73360

PLATE, OPERATING

45

21M-00-21280

PLATE

46

01010-81640

BOLT

47

01643-31645

WASHER
