Запчасти Komatsu PC290LC-10 ЦИЛИНДР СТРЕЛЫ, ВНУТР. ЧАСТИ, ЛЕВ. (№-) ЦИЛИНДР СТРЕЛЫ, С 9MM СТРЕЛА

|$0

707-E1-00380

Cylinder Assembly

1

721-13-14040

Cylinder

2

707-58-10801

Rod, Piston

3

707-76-80431

Bushing

4

07145-00080

Seal, Dust, (Kit : K02)

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust, (Kit : K02)

7

707-71-35160

Collar

8

707-35-31310

Ring, Back-up, (Kit : K02)

9

07000-B5130

O-ring, (Kit : K02)

10

707-71-71020

Plunger

11

707-27-14690

Head, Cylinder

12

707-56-10740

Seal, Dust, (Kit : K02)

13

07179-13114

Ring, Snap

14

707-52-90781

Bushing

15

707-51-10030

Packing, Rod

16

707-51-10650

Ring, Buffer, (Kit : K02)

17

707-35-31310

Ring, Back-up, (Kit : K02)

18

07000-B5130

O-ring

19

01010-81875

Bolt

20

707-41-11840

Washer

21

707-75-10160

Ring, Snap

22

707-36-14650

Piston

23

707-44-14150

Ring, Piston, (Kit : K02)

24

707-39-14110

Ring, Wear, (Kit : K02)

25

707-35-30900

Ring, Back-up, (Kit : K02)

26

07000-B5090

O-ring, (Kit : K02)

27

707-44-14910

Ring

28

01310-01216

Screw

29

707-86-69050

Tube, L.H.

30

707-86-00790

Tube, L.H.

31

707-88-51110

Bracket, L.H.

32

707-88-21321

Band

33

07283-32738

Clip, Pipe

34

07283-33442

Clip, Pipe

35

01597-01009

Nut

36

01643-31032

Washer

37

707-88-33030

Cap

38

07371-30640

Flange, Split

39

707-88-33040

Cap

40

07371-31049

Flange, Split

41

07372-21035

Bolt

42

01643-51032

Washer

43

07372-21060

Bolt

44

01643-51032

Washer

45

07372-21045

Bolt

46

01643-51032

Washer

47

07000-13030

O-ring, (Kit : K02)

48

07000-13035

O-ring, (Kit : K02)
