Запчасти Komatsu PC290LC-10 ГИДР. БАК. (№-) ГИДР. БАК., С -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР

1

206-60-35110

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

02781-00628

Union

5

02896-11018

O-ring

6

07002-12434

O-ring

7

02782-10524

Elbow

8

02896-11015

O-ring

9

07002-12434

O-ring

10

02782-10315

Elbow

11

02896-11009

O-ring

12

07002-12034

O-ring

13

07040-12412

Plug

14

07002-12434

O-ring

15

07040-12012

Plug

16

07002-12034

O-ring

17

20Y-62-45690

Tee

18

02896-11008

O-ring

19

02896-11009

O-ring

20

07002-12034

O-ring

21

207-60-71182

Element, Hydraulic Oil Filter

22

20Y-60-31140

Strainer

23

20Y-60-31131

Valve Assembly

24

20Y-60-21240

Spring

25

2A5-60-11150

Cover

26

07000-15195

O-ring

27

01010-81230

Bolt

28

01643-31232

Washer

|$28

2A5-60-11121

Strainer Assembly

29

2A5-60-11130

Rod Assembly

30

20Y-60-21320

Holder

31

12R-60-11230

Spring

32

22B-60-11160

Strainer

33

2A5-60-11141

Cover

34

07000-15160

O-ring

35

01010-81230

Bolt

36

01643-31232

Washer

37

22U-60-31120

Cap Assembly

38

20Y-60-21470

Element

39

208-60-71181

Filler Neck

40

20Y-60-21340

Gasket

41

01252-A0516

Bolt, Hexagon Socket Head

42

01601-20513

Washer

43

07285-00220

Clip

44

07261-21414

Hose

45

04434-52312

Clip

46

01010-81225

Bolt

47

01643-31232

Washer

48

205-00-73360

Plate, Operating

49

21M-00-21280

Plate

50

01010-81640

Bolt

51

01643-31645

Washer
