Запчасти Komatsu PC290LC-10 ГИДР. БАК. (№-) ГИДР. БАК.

1

206-60-35110

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

02781-00628

Union

5

02896-11018

O-ring

6

07002-12434

O-ring

7

02782-10524

Elbow

8

02896-11015

O-ring

9

07002-12434

O-ring

10

02782-10315

Elbow

11

02896-11009

O-ring

12

07002-12034

O-ring

13

07040-12412

Plug

14

07002-12434

O-ring

15

07040-12012

Plug

16

07002-12034

O-ring

17

207-60-71182

Element, Hydraulic Oil Filter

18

20Y-60-31140

Strainer

19

20Y-60-31131

Valve Assembly

20

20Y-60-21240

Spring

21

2A5-60-11150

Cover

22

07000-15195

O-ring

23

01010-81230

Bolt

24

01643-31232

Washer

|$24

2A5-60-11121

Strainer Assembly

25

2A5-60-11130

Rod Assembly

26

20Y-60-21320

Holder

27

12R-60-11230

Spring

28

22B-60-11160

Strainer

29

2A5-60-11141

Cover

30

07000-15160

O-ring

31

01010-81230

Bolt

32

01643-31232

Washer

33

22U-60-31120

Cap Assembly

34

20Y-60-21470

Element

35

208-60-71181

Filler Neck

36

20Y-60-21340

Gasket

37

01252-A0516

Bolt, Hexagon Socket Head

38

01601-20513

Washer

39

07285-00220

Clip

40

07261-21414

Hose

41

04434-52312

Clip

42

01010-81225

Bolt

43

01643-31232

Washer

44

205-00-73360

Plate, Operating

45

21M-00-21280

Plate

46

01010-81640

Bolt

47

01643-31645

Washer
