Запчасти Komatsu PC290LC-10 СИСТЕМА ОХЛАЖДЕНИЯ, ПОСЛЕОХЛАДИТЕЛЬ И КОЖУХ (№-) СИСТЕМА ОХЛАЖДЕНИЯ

1

206-03-35181

Shroud

2

01010-81030

Bolt

3

01643-31032

Washer

3

206-03-35310

Cover Assembly

4

Cover

5

206-03-35330

Sheet

6

01010-81030

Bolt

7

01643-31032

Washer

7

206-03-31421

Bracket Assembly

8

Bracket

9

2A5-03-11711

Sheet

10

01010-81030

Bolt

11

01643-31032

Washer

11

206-03-35480

Cover Assembly

12

206-03-31450

Sheet

13

Cover

14

206-03-35470

Sheet

15

01010-81020

Bolt

16

01643-31032

Washer

17

206-03-35141

Aftercooler Assembly

18

01010-81040

Bolt

19

01643-31032

Washer

20

208-03-41580

Collar

21

208-03-41590

Cushion

22

6110-23-6490

Spacer

23

206-03-31261

Bracket

24

01010-81020

Bolt

25

01643-31032

Washer

26

206-03-31271

Bracket

27

01010-81020

Bolt

28

01643-31032

Washer

29

2A5-03-11381

Hose

30

206-03-43340

Clip

31

206-03-35410

Sheet

32

2A5-03-11481

Sheet

33

2A5-03-11490

Sheet

34

2A5-03-11531

Sheet

35

206-03-31480

Sheet

36

206-03-21690

Sheet

37

2A5-03-11561

Sheet

38

2A5-03-11521

Sheet

39

206-03-35420

Sheet

40

2A5-03-11991

Sheet

41

2A5-03-11571

Sheet

42

206-03-35271

Cover

43

01010-81020

Bolt

44

01643-31032

Washer

45

20Y-03-41870

Seal
