Запчасти Komatsu PC290LC-10 ОСНОВН. ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/) ОСНОВН. ПОРШЕНЬ НАСОС

|$0

708-2G-00310

Pump Assembly

|$1

708-2G-01310

Pump Subassembly

1

708-2G-12610

Shaft, Front

2

708-2L-42250

Bearing

3

708-2E-05040

Washer Kit

3

Washer, T=3.1mm

3

Washer, T=3.0mm

3

Washer, T=2.9mm

3

Washer, T=2.8mm

4

708-25-12790

Ring, Snap

5

708-2L-32460

Seal, Oil

6

708-2L-22160

Spacer

7

04065-06825

Ring, Snap

|$13

708-2G-04640

Block Assembly, Front

8

Cylinder Block

9

Plate, Valve, Front

10

708-18-13230

Pin

11

04065-05820

Ring, Snap

12

708-2L-43130

Seat

13

708-2G-13760

Spring

14

708-2H-23141

Seat

15

708-2G-13740

Guide, Retainer

16

708-2L-43360

Pin

17

708-2G-13750

Retainer, Shoe

18

708-2L-43311

Piston Subassembly

|$25

708-2G-04660

Cradle Assembly

19

Cradle

20

Cam, Rocker

21

04020-01228

Pin, Dowel

22

01252-61025

Bolt
