Запчасти Komatsu PC290-8K ОСНОВН. ПОРШЕНЬ НАСОС (/)(№-) ГИДРАВЛИКА

|1

708-2L-01600

Pump Subassembly

1

Shaft, Front

2

Bearing

3

Washer Kit

|3

708-2E-12160

Washer, T=3.1mm

|3

708-2E-12170

Washer, T=3.0mm

|3

708-2E-12180

Washer, T=2.9mm

|3

708-2E-12190

Washer, T=2.8mm

4

Ring, Snap

5

708-25-52861

Seal, Oil

6

708-2L-22160

Spacer

7

04065-06825

Ring, Snap, for Hole Side

|8

Block Assembly, Front

8

708-2L-33190

Block, Cylinder

9

708-2L-33170

Plate, Valve

10

Pin

11

Ring, Snap, Snap

12

Seat

13

Spring

14

Seat

15

Guide, Retainer

16

Pin

17

Retainer, Shoe

18

Piston Subassembly

|19

Cradle Assembly

19

708-2L-23640

Cradle

20

708-2L-33450

Cam, Rocker

21

Pin

22

Bolt, Hexagon Socket Head
