Запчасти Komatsu PC290-8K КАБИНА (/)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

702-16-04250

Valve, Pilot

1

702-16-73660

Valve Body

2

702-16-53120

Valve

3

702-16-51140

Shim

4

702-16-53420

Spring

5

702-16-53140

Retainer

6

702-16-54420

Spring

7

702-16-53170

Piston

8

702-16-71150

Seal

9

702-16-71160

Seat

10

702-16-73630

Case

11

702-16-54121

Lever

12

702-16-73620

Shaft

13

702-16-73640

Plate

14

01010-80855

Bolt

15

01643-30823

Washer

16

01010-80816

Bolt

17

702-16-54331

Washer, T=1.60mm

18

04025-00432

Pin, Spring

19

702-16-54430

Bushing

20

07000-12018

O-ring

21

702-16-73610

Damper Assembly

22

01023-10306

Screw

23

702-16-73650

Pin

24

04022-04016

Pin, Dowel
