Запчасти Komatsu PC28UU-3 МОТОР ХОДА (/) (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21U-60-36111

TRAVEL MOTOR ASS'Y,TRAVEL

|1

FUPMV-1B2412AY

MOTOR SUB ASS'Y,TRAVEL

|1

FUMHB-1B24333

MOTOR ASS'Y

1

BODY SUB ASS'Y

2

PISTON

3

FUSCJY254010

SEAL,OIL (KIT)

4

FUFZD-4333-103

SHAFT

5

FU6205

BEARING

6

FUFZD-4500-141

PLATE,SWASH

7

20P-60-73360

BALL,STEEL

|8

FUMHCB-1-2448

CYLINDER BARREL A.

8

CYLINDER

9

PLATE,VALVE

10

PISTON

11

SHOE

12

HOLDER,SHOE

13

HOLDER,BARREL

14

PIN

15

SPRING

16

RETAINER

17

04065-02812

RING,SNAP

|18

FUMHB-1-Y-2448

BODY SUB ASS'Y

|18

BODY ASS'Y

18

BODY

19

SPOOL

20

CHECK VALVE

21

GUIDE,SPRING

22

SPOOL

23

SPRING

24

FUFZS-2448244

SPRING

25

FUFZS-2448259

SPRING

26

FUFZS-2448-26

PLUG

27

FUFZS-2448-27

PLUG

28

CHOKE

29

FUFZS-2448-30

RING

30

FURO-P25-90

O-RING (KIT)

31

07000-12014

O-RING (KIT)

32

FURO-P12.5-70

O-RING (KIT)

33

20M-60-25370

PLUG

34

FUFZS2448-22

SPOOL,SHUTTLE

35

FUFZS2448-28

PLUG

36

FURO-P8-90

O-RING

37

FUTPUA-1/16

PLUG

38

CHOKE

39

06000-06201

BEARING

40

04025-00512

PIN,SPRING

41

FURO-G125-90

O-RING (KIT)

42

FURO-P7-90

O-RING (KIT)

43

01252-41025

BOLT

44

20P-60-71330

PIN

KIT

FUMHS-1B-14336

SEAL KIT
