Запчасти Komatsu PC28UU-3 МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-7R-00081

MOTOR ASS'Y

|1

MOTOR SUB ASS'Y

1

708-7R-11621

PLATE,SWASH

2

708-7R-11710

WASHER

3

708-7R-11720

FILTER

|4

708-7R-04050

HOUSING SUB ASS'Y

4

HOUSING

5

PLUG

6

708-7R-11220

PLUG

7

07002-11223

O-RING

8

708-7R-11210

VALVE

9

722-10-91130

SPRING

10

709-32-12861

PLUG

11

07002-11823

O-RING

12

431-40-11210

O-RING

13

720-68-19610

PIN

14

01252-61230

BOLT

15

708-7R-12120

SHAFT

16

708-7R-12140

BEARING

17

708-7R-12150

BEARING

18

04065-04218

RING,SNAP

19

708-7R-13111

BLOCK,CYLINDER

20

708-7R-13230

PLATE,VALVE

21

720-68-19610

PIN

22

708-7R-13540

PIN

23

708-7R-13530

WASHER

24

708-7R-13560

SPRING

25

04065-03012

RING

26

708-7R-13510

GUIDE,RETAINER

27

708-7R-13351

RETAINER,SHOE

28

708-7R-13320

PISTON SUB ASS'Y

29

708-7R-13410

PLATE,THRUST

30

708-7R-13581

SPACER

31

708-7R-15130

PLATE

32

708-7R-15121

DISC

33

708-7R-15180

PISTON,BRAKE

34

07000-12115

O-RING

35

07000-12095

O-RING

36

708-7R-15150

SPRING

37

708-7R-15160

RING

38

708-7R-15712

PISTON

39

708-7R-15722

SPRING

|40

708-7R-03030

VALVE SUB ASS'Y

40

VALVE

41

FILTER

42

708-7R-15670

SPRING

43

706-73-72680

PLUG

44

07002-11223

O-RING
