Запчасти Komatsu PC28UU-2 ОСНОВН. КЛАПАН (/) (ДЛЯ НАКЛОНЯЕМ. МЕХАНИЧ. ANGLE)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

709-34-14400

CONTROL VALVE ASS'Y,PC28UU KE12

|$3

700-25-53000

VALVE

1

SLEEVE

2

POPPET

3

SPRING

4

SCREW

5

O-RING

6

NUT

7

700-22-11410

O-RING

8

07002-02434

O-RING

9

RING

10

VALVE

11

SPRING

|$15

709-30-65300

VALVE ASS'Y

12

SLEEVE

13

POPPET

14

PISTON

15

SPRING

16

SCREW

17

NUT

18

O-RING

19

709-32-11840

O-RING

20

07002-02034

O-RING

|$25

709-30-62301

VALVE ASS'Y

21

SLEEVE

22

VALVE

23

POPPET

24

SPRING

25

PISTON

26

SCREW

27

O-RING

28

NUT

29

SPRING

30

PLUG

31

SEAL

32

O-RING

33

07002-02034

O-RING

34

SEAL

|$40

709-30-62101

VALVE ASS'Y

35

SLEEVE

36

VALVE

37

POPPET

38

SPRING

39

PISTON

40

O-RING

41

NUT

42

SPRING

43

PLUG

44

SEAL

45

O-RING

46

07002-02034

O-RING

47

SEAL

48

SCREW

|$55

709-30-61100

VALVE ASS'Y

49

SLEEVE

50

VALVE

51

SEAL

52

SPRING

53

07002-02034

O-RING
