Запчасти Komatsu PC28UU-2 ГИДРОМОЛОТ (ВНУТР. ЧАСТИ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

21U-970-2211

BREAKER ASS'Y

1

21U-970-1100

CYLINDER

2

21U-970-1110

SEAL,DUST (KIT)

3

21U-970-1120

U-PACKING (KIT)

4

21U-970-1130

RETAINER,RETAINER

5

21U-970-1140

U-PACKING

6

21U-970-1410

U-PACKING (KIT)

7

21U-970-1150

O-RING (KIT)

8

21U-970-1160

PLUG

9

21U-970-1170

O-RING

10

21U-970-1180

PLUG

11

21U-970-1190

O-RING

12

21U-970-1200

PLUG

13

21U-970-1210

O-RING

14

21U-970-1220

PLUG

15

21U-970-1230

PISTON

16

21U-970-1240

VALVE

17

21U-970-1250

HEAD,FRONT

18

21U-970-1260

BUSHING,FRONT

19

21U-970-1270

BUSHING,THRUST

20

21U-970-1280

RING,SNAP

21

20P-70-71230

BUSHING

22

07144-10304

BUSHING

23

07145-00035

SEAL,DUST

24

21U-970-1290

PIN,STOP

25

21U-970-1300

PIN,SPRING

26

21U-970-1310

NIPPLE

27

07020-00000

FITTING,GREASE

28

21U-970-1320

PIN,ROD

29

21U-970-1330

PIN,RING

30

21U-970-1360

HEAD,BACK

31

21U-970-1370

VALVE,CHARGING (KIT)

32

21U-970-1380

BOLT,THROUGH

33

21U-970-1390

NUT

34

21U-970-1400

WASHER (KIT)

35

21U-970-1420

PLATE

36

20C-970-2160

CHISEL

37

21U-970-2181

DUMMY CHISEL

|38

21U-970-1430

ACCESSORY ASS'Y

38

21U-970-1440

CASE,WRENCH

39

21U-970-1450

BOMB,CHARGING

40

21U-970-1460

HOLDER,CHARGING

41

21U-970-1470

ADAPTER,CHECK

42

21U-970-1480

GAUGE,PRESSURE

KIT

21U-970-1490

SEAL KIT
