Запчасти Komatsu PC28UU-2 ПЕРЕДН. COVER ЧАСТИ КОРПУСА

|1

21U-46-21400

COVER ASS'Y,L.H.

1

COVER

1A

21U-54-21830

SHEET

|2

21U-46-21500

COVER ASS'Y,R.H.

2

COVER

2A

21U-54-21840

SHEET

3

01010-51025

BOLT

4

21U-54-21760

WASHER

5

21U-54-21620

COVER

6

21U-54-21630

PLATE

7

20U-54-21570

CAP

7A

20U-54-21820

NUT

8

01435-01016

BOLT

9

21U-54-21640

COVER

10

21U-54-21651

PLATE

|10

21U-54-21652

PLATE,(WITH MIRROR)

|10

21U-54-21651

PLATE

11

20U-54-21570

CAP

11A

20U-54-21820

NUT

12

21U-54-21661

HINGE

13

01010-51020

BOLT

14

01010-51030

BOLT

15

01643-31032

WASHER

16

21U-54-21610

LOCK ASS'Y

17

01010-51016

BOLT

18

01643-31032

WASHER

19

21U-54-21681

BRACKET

20

01010-51020

BOLT

21

01643-31032

WASHER

22

21U-54-21690

PLATE

23

01640-20816

WASHER

24

04205-30825

PIN

25

04052-10833

PIN,SNAP

26

21U-54-21671

PLATE

27

01435-01020

BOLT

28

205-54-51970

DOVE TAIL

29

205-54-53550

DOVE TAIL

30

01435-00612

BOLT

31

21U-54-21790

GROMMET

32

21U-54-21811

SHEET

|32

21U-54-21810

SHEET

33

21U-54-21822

SHEET

|33

21U-54-21821

SHEET

34

01010-51020

BOLT

35

20U-54-21890

SHEET

36

21U-54-21550

SHEET

37

FF7814-54910

MIRROR
