Запчасти Komatsu PC28UD-2 ОСНОВН. КЛАПАН (/)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

709-33-14300

CONTROL VALVE ASS'Y

|1

709-33-00141

VALVE SUB ASS'Y

|1

709-33-10900

BODY SUB ASS'Y

1

BLOCK

2

BLOCK

3

BLOCK

4

BLOCK

5

COVER

6

07000-12055

O-RING

7

709-33-11510

STUD

8

01580-10806

NUT

9

SPOOL

10

SPOOL

11

SPOOL

12

709-32-11530

SEAL

13

709-32-11540

PLATE

14

01252-60610

BOLT

15

709-32-11550

RETAINER

16

709-32-11560

COLLAR

17

709-32-11580

SPRING

18

01252-60620

BOLT

19

709-32-11570

COVER

20

01252-60616

BOLT

21

04260-01270

BALL

22

709-32-11820

SPRING

23

709-32-11810

PLUG

24

07002-11823

O-RING

25

709-32-11830

PLUG

26

709-32-11840

O-RING

27

07002-12034

O-RING

28

01252-60622

BOLT

29

01641-20608

WASHER

30

709-32-12851

CASE

31

709-32-13510

SPRING

32

709-32-12840

RETAINER

33

709-32-11760

O-RING
