Запчасти Komatsu PC27R-8 ЛЕНИВЕЦ (ДЛЯ STEEL SHOE) (/) ХОДОВАЯ
7
16
17
6
5
4
3
2
1
16
17
15
13
14
12
11
10
9
8
A
\0
3F1027054
IDLER, L.H., ASSY.
\0
3F1027055
IDLER, R.H., ASSY.
1
200514055
CYLINDER
2
855661403
O-RING
3
855661406
RING, WEAR
4
500256358
SPACER
5
855661226
GASKET
6
802250552
RING, SNAP
7
500327259
PISTON
8
3F1027050
PISTON ROD
9
804040015
SPRING
10
3F1027605
PLATE
11
801070025
NUT
12
802610087
PIN, COTTER
13
3F1027051
VALVE
14
860010009
FITTING
15
500158818
PLATE
16
801015577
BOLT
17
802170003
WASHER
