Запчасти Komatsu PC27R-8 СИСТЕМА ОХЛАЖДЕНИЯ ДВИГАТЕЛЬ

\0

871070061

ENGINE, ASSY.

1

YM119802-42000

PUMP, ASSY.

3

YM119810-42051

GASKET

4

YM119810-42120

PLATE

8

YM119810-42281

GASKET

9

YM119810-42290

PIPE

11

YM129150-42320

O-RING

13

YM23876-030000

PLUG

14

YM26106-060142

BOLT

15

YM26106-060202

BOLT

16

YM26106-080352

BOLT

17

YM26106-080552

BOLT

18

YM119831-42290

V-BELT

19

YM129403-42380

PULLEY

20

YM129350-49530

COVER, THERMOSTAT

21

YM129795-49551

GASKET

22

YM121250-44901

WATER TEMPERATURE TRANSMITTER (ALARM)

23

YM124465-44950

GASKET

24

YM121450-42450

PLUG

25

YM26106-080222

SCREW

26

YM129155-49801

THERMOSTAT

27

YM129150-49811

GASKET

28

YM23414-080000

GASKET

29

YM26106-080122

BOLT

30

YM129354-44740

FAN, COOLING

31

YM119802-49610

PIPE, ASSY.

32

YM119802-49711

PIPE, ASSY.

33

YM119802-49730

CLAMP

34

YM124722-59050

CLAMP

35

YM119802-59320

PIPE

36

YM119802-49620

PIPE, ASSY.

37

YM119802-49721

PIPE

38

YM124722-59050

CLAMP

39

YM171353-44760

SPACER

40

YM26106-060402

SCREW

41

YM129486-42050

GASKET

42

YM129150-49360

GASKET
