Запчасти Komatsu PC27R-8 ТОПЛ. НАСОС ДВИГАТЕЛЬ

\0

871070022

MOTOR, ASSY.

1

YM719866-51390

INJECTION PUMP, ASSY.

2

REGULATOR, ASSY.

3

INJECTION PUMP

4

YM129155-51020

STUD

5

YM129211-51040

CAMSHAFT

6

YM129155-51050

BEARING

7

YM129155-51060

COVER

8

YM122710-51090

KEY

9

YM129108-51100

PLUNGER W/BARREL

12

YM129155-51140

PIN

13

YM174307-51170

RETAINER, SPRING

14

YM129155-51180

SEAT, NOZZLE SPRING

15

YM124950-51190

SPRING

16

YM129155-51200

TAPPET, ASSY

23

YM129155-51270

LOCKING, TAPPET

24

YM129155-51280

O-RING

25

YM129505-51300

VALVE DELIVERY

28

YM129155-51320

SPRING

29

YM129155-51340

GUARD, DELIVERY VALVE

30

YM124550-51350

GASKET

31

YM124550-51370

O-RING

32

YM129155-51370

STOPPER

33

YM129155-51380

LOCKING (A)

34

YM129155-51390

LOCKING (B)

35

YM129155-51400

DEFLECTOR

36

YM129155-51410

CHECK BOLT

37

YM129155-51420

PLUG

38

YM129155-51450

KIT, SHIM

43

YM129155-51500

RACK

44

YM129155-51521

BUSHING

45

YM129155-51530

SPACER

46

YM129155-51540

RING, SNAP

47

YM129155-51550

PINION

48

YM122117-51560

SCREW

49

YM174307-51560

PINION

50

YM129155-51570

PLUG

51

YM129155-51580

O-RING

52

YM129155-51591

SPRING

53

YM129155-51600

KIT, SHIM

72

YM129155-51700

COVER

73

YM129155-51710

GASKET

74

YM129155-51750

COVER

75

YM129155-51760

GASKET

76

YM129155-51790

LOCKING, RACK

77

YM129156-51910

PLATE, CAUTION

78

YM129155-51930

SPACER, T=3.25

79

YM129155-51940

SPACER, T=1.5

80

YM22217-050000

SPRING WASHER

81

YM22217-060000

SPRING WASHER

82

YM22351-050010

PEG

83

YM24101-063034

BEARING

84

YM24341-000160

O-RING

85

YM26022-050102

SCREW

86

YM26022-060162

SCREW

87

YM26116-050302

SCREW

88

YM26716-060002

NUT

89

YM22190-160002

GASKET

91

COVER

92

YM129155-52050

GASKET

93

YM129100-52200

COVER
