Запчасти Komatsu PC27R-8 СЕРВИСНЫЙ КЛАПАН (-НАВЕСН. ОБОРУД) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

723-12-00031

VALVE ASS'Y

|$3

723-12-00030

VALVE ASS'Y

|$4

723-11-00151

VALVE SUB ASS'Y

|$5

723-11-00150

VALVE SUB ASS'Y

1

BLOCK,VALVE

2

SPOOL

3

723-11-17450

PLUG

4

07002-10823

O-RING

5

723-11-17330

RETAINER

6

723-11-17350

RETAINER

7

723-11-17431

RETAINER

7

723-11-17430

RETAINER

8

723-11-17360

BOLT

9

723-11-17340

SPRING

10

723-11-27290

CASE,SPRING

11

723-11-17410

CASE,SPRING

12

01252-60640

BOLT

13

01252-60620

BOLT

14

722-12-19120

O-RING

15

723-11-18170

VALVE

16

723-11-18190

PLUG

17

723-11-18180

SPRING

18

07002-11023

O-RING

19

VALVE

20

VALVE

21

723-11-16230

SPRING

22

723-11-15130

SPRING

23

PISTON

24

723-11-15110

PLUG

25

07002-11623

O-RING

26

07000-12100

O-RING

27

723-11-19110

O-RING

28

723-11-19150

RING

29

723-11-19130

O-RING

30

07000-11007

O-RING

|$37

723-20-80100

VALVE ASS'Y,SUCTION

31

SLEEVE

32

VALVE

33

SPRING

34

SEAL

35

07002-02034

O-RING

36

6132-11-4690

BOLT

37

01643-50823

WASHER
