Запчасти Komatsu PC27R-8 МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

20P-26-81001

SWING MACHINERY A.

|$3

708-7R-00511

MOTOR ASS'Y

|$5

MOTOR SUB ASS'Y

1

708-7R-11812

PLATE,SWASH

2

708-7R-11710

WASHER

3

708-7R-11720

FILTER

|$9

708-7R-04021

HOUSING SUB ASS'Y

4

HOUSING

5

PLUG

6

708-7R-11220

PLUG

7

07002-11223

O-RING

8

708-7R-11210

VALVE

9

722-10-91130

SPRING

10

709-32-12861

PLUG

11

07002-11823

O-RING

12

07000-02125

O-RING

13

720-68-19610

PIN

14

01252-61230

BOLT

15

708-7R-12111

SHAFT

16

708-7R-12140

BEARING

17

708-7R-12150

BEARING

18

04065-04218

RING,SNAP

19

708-7R-13111

BLOCK,CYLINDER

20

708-7R-13210

PLATE,VALVE

21

720-68-19610

PIN

22

708-7R-13540

PIN

23

708-7R-13530

WASHER

24

708-7R-13520

SPRING

25

04065-03012

RING

26

708-7R-13510

GUIDE,RETAINER

27

708-7R-13340

RETAINER,SHOE

28

708-7R-13310

PISTON SUB ASS'Y

29

708-7R-13410

PLATE,THRUST

30

708-7R-13570

SPACER

31

708-7R-15130

PLATE

32

708-7R-15121

DISC

33

708-7R-15140

PISTON,BRAKE

34

07000-12110

O-RING

35

708-7R-15170

RING,BACK-UP

36

07000-12095

O-RING

37

07001-02095

RING,BACK-UP

38

708-7R-15150

SPRING

39

708-7R-15160

RING

40

708-7R-15712

PISTON

41

708-7R-15722

SPRING

|$48

708-7R-03010

VALVE SUB ASS'Y

42

VALVE

43

FILTER

44

708-7R-15670

SPRING

45

706-73-72680

PLUG

46

07002-11223

O-RING
