Запчасти Komatsu PC27R-8 DELUXE РЕГУЛЯТОР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC27R-8 DELUXE - РЕГУЛЯТОР ДВИГАТЕЛЬ
A
A
82
B
B
66
C
C
A
A
77
114
74
66
79
70
61
24
5
6
62
69
65
72
73
64
17
75
83
59
81
20
115
76
78
4
60
25
71
33
7
8
9
32
68
26
80
33
63
68
10
51
26
14
31
77
15
67
16
2

Артикул

Название

Примечание

Количество

\0

871070045

ENGINE, ASSY.

\0

YM719866-51450

INJECTION PUMP, ASSY.

\0

REGULATOR, ASSY.

2

YM129155-51280

O-RING

4

YM129052-61050

GASKET

5

YM129052-61060

COVER

6

YM129052-61070

GASKET

7

YM129155-61120

LINK L=30 (0)

8

YM129155-61130

LINK L=31 (1)

9

YM129155-61140

LINK L=30.5 (0.5)

10

YM129486-61201

WEIGHT ASSY., GOVERNOR

14

YM129155-61341

SLEEVE

15

YM129155-61350

SLEEVE

16

YM129155-61360

SLEEVE

17

YM129100-61400

SHAFT, CONTROL

20

YM129155-61430

SPACER

24

YM129155-61450

BOLT, REVOL. LIMIT

25

YM129155-61460

BOLT, IDLE LIMIT

26

YM129155-61480

SPACER

31

YM129052-61390

SHAFT, GOVERNOR LEVER

32

YM119908-61501

TORQUE SPRING ASSY.

33

YM174307-51700

KIT, SHIM

51

YM129486-61540

SPRING

59

YM129155-61830

O-RING

60

YM119660-61901

RETAINER, SHAFT

61

YM129155-61950

SCREW

62

YM124550-66370

NUT

63

YM22117-040000

WASHER

64

YM22190-060003

SPRING WASHER

65

YM22190-100002

GASKET

66

YM22190-120002

SPRING WASHER

67

YM22287-120000

WASHER

68

YM22372-040000

PIN

69

YM23887-100002

PLUG

70

YM24341-000280

O-RING

71

YM26106-060102

BOLT PLATED

72

YM26106-060102

BOLT PLATED

73

YM26106-060102

BOLT PLATED

74

YM26106-060142

BOLT

75

YM26106-060202

BOLT

76

YM26756-060002

NUT

77

YM26776-120002

NUT

78

YM129100-61440

HANDLE

79

YM120323-61470

SCREW

80

YM129100-61650

SPRING

81

YM171353-61710

SPRING

82

YM129100-61930

CAP NUT

83

YM171353-61550

ANGLEICH ASSY.

114

YM119233-77931

COIL

115

YM26366-080002

NUT

Выбрано товаров: 50
