Запчасти Komatsu PC27MRX-1 DECEL МОТОР КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

22L-972-1230

MOTOR ASS'Y

2

01023-10614

SCREW

3

22L-972-1211

BRACKET

4

21U-972-3260

SEAL

5

01010-80816

BOLT

6

01643-30823

WASHER

6

01643-30823

WASHER

7

21U-972-3280

SHAFT,FLEXIBLE

8

21U-972-3270

SHAFT

9

21W-43-21283

BOSS

10

21W-43-21260

BOSS

11

21W-43-21241

PIN,SPRING

12

04025-00308

PIN,SPRING

13

21W-43-21230

PLATE

14

21W-43-21251

DIAL

15

21W-98-21582

PLATE, OPERATING

16

21W-06-21310

LAMP

17

20U-06-21381

CONTROLLER ASS'Y

18

01580-10806

NUT

19

01643-30823

WASHER

20

22L-972-1240

WIRING HARNESS

21

08034-20414

BAND

22

114-06-48542

SWITCH, KNOB

23

08034-30521

BAND

24

22F-06-11160

BRACKET

24

21U-06-31170

CLIP

25

21W-98-21620

PLATE

26

21U-972-3510

BRACKET

27

01010-80630

BOLT

28

01643-30623

WASHER

29

01643-30623

WASHER

30

01580-10605

NUT

31

22L-972-1222

BRACKET,R.H.

31

22L-972-1221

BRACKET,R.H.

31

06124-01616

BEARING

32

22L-972-1252

COVER

32

22L-972-1251

COVER

33

04050-12015

PIN,COTTER

34

22L-972-1260

PLATE

35

01220-40410

SCREW

36

01640-20408

WASHER
