Запчасти Komatsu PC27MRX-1 ОСНОВН. КЛАПАН (8-КЛАПАН) (9/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$3

723-18-14901

CONTROL VALVE

|$4

723-18-14900

CONTROL VALVE

|$5

723-18-14201

CONTROL VALVE

1

723-11-18280

VALVE

2

723-11-18290

SPRING

3

723-26-15230

PLUG

4

07002-12434

O-RING

5

SPOOL

6

SEAL

7

VALVE

8

723-11-18220

SPRING

9

723-11-18250

SPRING

10

723-11-18570

SLEEVE

11

720-68-19760

O-RING

12

723-11-18150

O-RING

13

723-11-18160

RING

14

VALVE

15

VALVE

16

VALVE

17

VALVE

18

VALVE

19

ORIFICE

20

PISTON

21

VALVE

22

VALVE

23

VALVE

24

VALVE

25

PISTON

26

SPACER

27

723-11-16230

SPRING

28

723-11-15130

SPRING

29

723-11-15110

PLUG

30

07002-11623

O-RING

31

ORIFICE

32

PISTON

33

SCREW

34

723-11-15180

SLEEVE

35

723-11-15190

SPRING

36

723-11-16270

PLUG

37

723-11-16290

SPRING

38

01583-11207

NUT

39

07000-11006

O-RING

40

07001-01006

RING

41

709-25-11650

VALVE,CHECK

42

723-11-28140

PLUG

43

723-11-18830

SPRING

43

723-11-18590

SPRING
