Запчасти Komatsu PC27MRX-1 МОТОР ХОДА (/) (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

21U-60-36210

MOTOR ASS'Y,TRAVEL

|$2

FUPMV-1B2412AY

MOTOR SUB ASS'Y,TRAVEL

|$3

FUMHB-1B24333

MOTOR ASS'Y

1

BODY SUB ASS'Y

2

PISTON

3

FUSCJY254010

SEAL,OIL (KIT)

4

FUFZD-4333-103

SHAFT

5

FU6205

BEARING

6

FUFZD-4500-141

PLATE,SWASH

7

FUYB-5/8

BALL,STEEL

|$11

FUMHCB-1-2448

CYLINDER BARREL A.

8

CYLINDER

9

PLATE,VALVE

10

PISTON

11

SHOE

12

HOLDER,SHOE

13

HOLDER,BARREL

14

PIN

15

SPRING

16

RETAINER

17

FURH-28

RING,SNAP

|$22

FUMHB-1-Y-2448

BODY SUB ASS'Y

|$23

BODY ASS'Y

18

BODY

19

SPOOL

20

CHECK VALVE

21

GUIDE,SPRING

22

SPOOL

23

SPRING

24

FUFZS-2448244

SPRING

25

FUFZS-2448259

SPRING

26

FUFZS-2448-26

PLUG

27

FUFZS-2448-27

PLUG

28

CHOKE

29

FUFZS-2448-30

RING

30

FURO-P25-90

O-RING (KIT)

31

FURO-P14-90

O-RING (KIT)

32

FURO-P12.5-70

O-RING

33

FUTPHA-1/8

PLUG

34

FUFZS2448-22

SPOOL,SHUTTLE

35

FUFZS2448-28

PLUG

36

FURO-P8-90

O-RING (KIT)

37

FUTPUA-1/16

PLUG

38

CHOKE

39

06000-06201

BEARING

40

FUPPS-W-5X12

PIN,SPRING

41

FURO-G125-90

O-RING (KIT)

42

FURO-P7-90

O-RING (KIT)

43

FUTH-10X25

SCREW

44

FUPP-H7-8X15

PIN

KIT

FUMHS-1B-14336

SEAL KIT
