Запчасти Komatsu PC27MR-2 ГИДРОЛИНИЯ (ГИДРОЛИНИЯ СТРЕЛЫ) (КЛАПАН БЕЗОПАСНОСТИ) (С ДАТЧИКОМS) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

1

22L-09-R2T20

VALVE, ASSY.

2

845250548

KIT, GASKET

3

22L-931-2150

UNION

4

37D-09-66105

UNION

5

37B-09-15617

O-RING

6

02896-11009

O-RING

7

226-09-12690

UNION

8

21D-09-69960

O-RING

9

02896-11008

O-RING

10

226-09-12790

ELBOW

11

21D-09-69960

O-RING

12

02896-11008

O-RING

13

22L-09-R1680

UNION

14

21D-09-69960

O-RING

15

37B-09-88002

O-RING

16

37D-09-7R870

TEE

17

02896-11008

O-RING

18

37D-09-6X460

ELBOW

19

02896-11008

O-RING

20

37D-09-7R870

TEE

21

02896-11008

O-RING

22

22L-60-23140

CLAMP

23

22L-60-23190

HOSE

24

22L-60-23180

HOSE

25

22L-62-R8150

HOSE

26

22L-09-R1670

PROTECTION

27

08034-20823

CLAMP

28

22L-60-23130

SUPPORT

29

01016-50825

BOLT

30

20S-60-13120

VALVE

31

01252-70540

BOLT

32

01640-20508

WASHER

33

21D-09-23140

NUT, STOP

34

226-09-12790

ELBOW

35

21D-09-69960

O-RING

36

02896-11008

O-RING

37

22L-60-23170

HOSE

38

22L-09-R1690

WIRING HARNESS

39

22L-09-R1970

WIRING HARNESS

40

22L-09-R1980

WIRING HARNESS

41

08034-20519

CLAMP

42

22L-09-R2T40

PUSH-BUTTON

43

22L-09-R2T80

GLASS

44

22L-09-R7520

PIPE

45

02896-11009

O-RING

46

08034-20834

CLAMP

47

22l-09-R7480

BRACKET

48

01010-80850

BOLT

49

01643-10823

WASHER

50

21D-09-81940

CLAMP
