Запчасти Komatsu PC27MR-2 СИСТЕМА ПОДОГРЕВА (/) ЧАСТИ КОРПУСА И КАБИНА

Схема запчастей Komatsu PC27MR-2 - СИСТЕМА ПОДОГРЕВА (/) ЧАСТИ КОРПУСА И КАБИНА
28
29
30
27
31
6
8
26
35
23
7
14
34
25
36
15
24
33
22
13
21
3
17
26
9
18
1
16
5
32
4
19
20
22
11
21
10
26
2
12

Артикул

Название

Примечание

Количество

1

22M-979-R410

HEATER AIR, ASSEMBLY

2

22L-09-R6510

HEATER CONTROL DEVICE

3

01643-10823

WASHER

4

01010-D1025

BOLT

5

01643-11032

WASHER

6

22B-979-R740

AIR FILTER CARTRIDGE

7

22M-979-2181

PLATE

8

22M-979-R290

CONNECTOR

9

22M-979-R421

HEATER CONTROL, ASSEMBLY

10

22L-09-R2370

KNOB

11

22L-09-R2360

KNOB

12

885081164

SWITCH, FAN CONTROL

13

01010-D0820

BOLT

14

01643-10623

WASHER

15

22M-979-2480

PLATE

16

01010-D0816

BOLT

17

01643-10823

WASHER

18

22M-979-R120

DUCT

19

01010-D1025

BOLT

20

01643-11032

WASHER

21

01252-70612

BOLT, HEXAGON SOCKET HEAD

22

01643-10623

WASHER

23

22M-54-25591

PLATE

24

01252-70612

BOLT, HEXAGON SOCKET HEAD

25

01643-10623

WASHER

26

22M-979-2460

AIR LOUVER

\26

22M-979-2161

COVER, ASSY.

27

22M-979-2191

COVER

28

22M-979-2390

BOLT

29

22M-979-2430

PLATE

30

37A-09-1W057

SCREW

31

01643-10623

WASHER

32

22M-979-2490

PLATE

33

22M-979-2151

BRACKET

34

01252-70612

BOLT, HEXAGON SOCKET HEAD

35

01643-10623

WASHER

36

37A-09-1W057

SCREW

Выбрано товаров: 37
