Запчасти Komatsu PC27MR-2-B МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-7R-00380

MOTOR ASS'Y

|1

MOTOR SUB ASS'Y

1

708-7R-11650

PLATE,SWASH

2

708-7R-11730

WASHER

3

702-21-54930

FILTER

|4

708-7R-04150

HOUSING SUB ASS'Y

4

HOUSING

5

PLUG

6

708-7R-11220

PLUG

7

07002-11223

O-RING

8

708-7R-11210

VALVE

9

722-10-91130

SPRING

10

708-7R-11290

PLUG

11

07002-11823

O-RING

12

431-40-11210

O-RING

13

720-68-19610

PIN

14

01252-61230

BOLT

15

708-7R-12130

SHAFT

16

708-7R-12140

BEARING

17

708-7R-12150

BEARING

18

04065-04218

RING

19

708-7R-13130

BLOCK,CYLINDER

20

708-7R-13260

PLATE,VALVE

21

720-68-19610

PIN

22

708-7R-13540

PIN

23

708-7R-13530

WASHER

24

708-7R-13560

SPRING

25

04065-03012

RING

26

708-7R-13590

GUIDE,RETAINER

27

708-7R-13370

RETAINER,SHOE

28

708-7R-13320

PISTON SUB ASS'Y

29

708-7R-13420

PLATE,THRUST

30

708-7R-15131

PLATE

31

708-7R-15122

DISC

32

708-7R-15211

PISTON,BRAKE

33

07000-12115

O-RING

34

07000-12085

O-RING

35

708-7R-15241

RING,BRAKE

36

07000-12100

O-RING

37

708-7R-15230

SPRING

38

723-30-51130

ORIFICE
