Запчасти Komatsu PC270LL-7L ЦИЛИНДР СТРЕЛЫ(БОЛЬШ. DIAMETER ТИП) РАБОЧЕЕ ОБОРУДОВАНИЕ

G-1

707-01-XA390

CYLINDER ASS'Y,L.H.

G-2

707-01-XA400

CYLINDER GROUP,R.H.

|$2

707-01-0A390

CYLINDER ASS'Y

1

707-13-14560

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL (KIT)

4

707-58-10690

ROD

5

707-76-80431

BUSHING

6

07145-00080

SEAL (KIT)

7

707-27-14930

HEAD

8

07179-13114

RING

9

176-63-56170

SEAL (KIT)

10

707-52-90780

BUSHING

11

707-51-10030

PACKING (KIT)

12

07000-15130

O-RING (KIT)

13

707-35-91420

RING (KIT)

14

707-51-10640

RING (KIT)

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-14650

PISTON

18

707-44-14180

RING (KIT)

19

707-39-14110

RING (KIT)

20

707-44-14910

RING

21

707-71-71020

PLUNGER

22

07000-15090

O-RING (KIT)

23

07001-05090

RING (KIT)

24

01310-01216

SCREW

25

707-71-34810

COLLAR

26

707-35-91420

RING (KIT)

27

07000-15130

O-RING (KIT)

28

707-86-66360

TUBE

29

707-86-66370

TUBE

30

01435-01055

BOLT

31

01435-01040

BOLT

32

07000-13030

O-RING (KIT)

33

707-88-22650

BRACKET,L.H.

|$36

707-88-22660

BRACKET,R.H.

34

707-88-21341

BAND

35

01435-01030

BOLT

36

07283-22738

CLIP

37

01599-01011

NUT

38

01643-31032

WASHER

39

707-88-33030

CAP,(FOR SHIPPING)

40

07371-30640

FLANGE,(FOR SHIPPING)

41

07372-21035

BOLT,(FOR SHIPPING)

42

01643-31032

WASHER,(FOR SHIPPING)

|$47

707-99-58050

SERVICE KIT
