Запчасти Komatsu PC270LC-8N1-W1 ГИДРАВЛ МАСЛ. БАК (С КЛАПАН ПЕРЕГРУЗКИ СТРЕЛЫ)(№-) ГИДРАВЛИКА

1

20Y-60-41113

TANK

1

20Y-60-41112

TANK

2

203-60-31100

ELBOW ASS'Y

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-12434

O-RING

6

02781-00628

UNION

7

02896-11018

O-RING

8

07002-12434

O-RING

9

02782-10522

ELBOW

10

02896-11015

O-RING

11

07002-12434

O-RING

12

02782-10315

ELBOW

13

02896-11009

O-RING

14

07002-12034

O-RING

15

02782-10311

ELBOW

16

02896-11009

O-RING

17

07002-11423

O-RING

18

20Y-62-15660

ADAPTER

19

07002-12034

O-RING

20

02782-10516

ELBOW

21

02896-11015

O-RING

22

07002-12034

O-RING

23

02783-10315

ELBOW

24

02896-11009

O-RING

25

07002-12034

O-RING

26

07040-12012

PLUG

27

07002-12034

O-RING

28

207-60-71182

ELEMENT

29

20Y-60-31140

STRAINER

30

20Y-60-31131

VALVE ASS'Y

31

20Y-60-21240

SPRING

32

22U-60-21232

COVER

33

07000-15195

O-RING

34

01010-81230

BOLT

35

01643-31232

WASHER

|$51

20Y-60-31171

STRAINER ASS'Y

36

207-60-61150

ROD ASS'Y

37

20Y-60-21320

HOLDER

38

12R-60-11230

SPRING

39

22B-60-11160

STRAINER

40

20Y-60-41212

COVER

41

07000-15160

O-RING

42

01010-81230

BOLT

43

01643-31232

WASHER

44

17A-60-11310

CAP ASS'Y

45

20Y-60-21470

ELEMENT

46

208-60-71180

FILLER NECK

47

20Y-60-21340

GASKET

48

01252-70516

BOLT

49

01601-20513

WASHER

50

07285-00155

CLIP

51

206-60-41240

TUBE

52

20Y-60-31271

BREATHER

52

20Y-60-31270

BREATHER

53

207-60-51311

ELEMENT

53

207-60-51310

ELEMENT

54

207-60-51320

SEAL

55

01252-70516

BOLT

56

01601-20513

WASHER

57

205-00-73360

PLATE, OPERATING

58

01010-81635

BOLT

59

01643-31645

WASHER
