Запчасти Komatsu PC270LC-8N1-W1 ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

723-47-23302

VALVE ASS'Y

|$3

723-47-23300

VALVE ASS'Y

|$5

723-40-72100

VALVE ASS'Y

1

BODY

2

SPOOL

3

723-40-72800

PLATE ASS'Y

4

702-21-60500

PILOT VALVE

5

723-11-19960

O-RING

6

702-21-54910

O-RING

7

723-46-15111

CASE

8

07430-71380

O-RING

9

723-40-71330

RETAINER

10

723-40-71340

SPRING

11

723-40-71350

RETAINER

12

01252-60816

BOLT

13

723-40-71870

UNION

14

02896-11008

O-RING

15

07002-11423

O-RING

16

07040-11409

PLUG

17

07002-11423

O-RING

18

01252-60855

BOLT

19

01252-60635

BOLT

|$25

723-40-72900

SPOOL ASS'Y

20

SPOOL

21

723-40-71850

SPRING

22

723-46-18720

O-RING

23

SPOOL

24

723-40-71390

SPRING

25

723-46-18720

O-RING

|$32

723-40-71900

VALVE ASS'Y

26

VALVE ASS'Y,RELIEF

27

702-16-53920

O-RING

28

07002-11623

O-RING

29

BLOCK

30

SPOOL

31

SPRING

32

702-21-55620

PLUG

33

07002-11423

O-RING

34

702-21-55710

SEAT

35

702-21-55720

SPRING

36

04260-00793

BALL

37

07000-11009

O-RING

38

PLUG
