Запчасти Komatsu PC270LC-8 A-AA ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ

|$0

6754-82-8060

TURBOCHARGER

|$1

NSS

TURBOCHARGER

1

6735-81-6810

SPACER, MOUNTING

2

6736-81-8370

BEARING, TURBOCHARGER

3

6731-82-8210

NUT, LOCK

4

6733-81-8650

WASHER, PLAIN

5

6736-81-8480

BOLT

6

6736-81-8430

SHIELD, TURBOCHARGER HEAT

7

6736-81-8280

SHAFT & WHEEL

8

6733-81-8360

RING, RETAINING

9

NSS

DATAPLATE

10

6736-81-8360

RING, RETAINING

11

6732-81-8140

COUPLING, ELBOW HOSE

12

NSS

END, ADJUSTING LINK

13

6743-82-8610

NUT

14

6733-81-8370

RING, RETAINING

15

6733-81-8460

SEAL, O RING

16

6733-81-8380

BOLT (M8-1.25x20)

17

6733-81-8270

PLATE, OIL SEAL

18

6733-81-8260

SLINGER, OIL

19

NSS

ACTUATOR, TURBOCHARGER

20

6733-81-6850

SPACER, MOUNTING

21

NSS

BAFFLE, TURBOCHARGER NOISE

22

6735-82-8220

BEARING, TURBOCHARGER THRUST

23

6735-81-8620

COLLAR, THRUST

24

6735-81-8370

BOLT

25

NSS

IMPELLER, TURBOCHARGER COMPRESSOR

26

6733-81-8480

PIN, ROLL

27

NSS

HOUSING, TURBOCHARGER BEARING

28

1304 920 H1

PLATE, CLAMPING

29

6742-01-5569

BOLT

30

1317 714 H1

HOUSING, TURBINE

31

6735-81-8310

RING, RETAINING

32

6735-81-8490

BRACKET, ACTUATOR

33

6733-51-8110

GASKET, ADAPTER

34

6742-01-5564

CLAMP, HOSE

35

6733-81-8320

CONNECTION, ADAPTER

36

6742-01-5566

HOSE, PLAIN

37

NSS

HOUSING, COMPRESSOR

38

6736-81-8440

SEAL, SPLIT RING

39

6736-81-8320

SEAL, SPLIT RING

40

6736-81-8380

BOLT (M8-1.25x12)

41

6733-81-8330

BAFFLE, OIL

42

6743-82-8140

RING, RETAINING
