Запчасти Komatsu PC270LC-8 C-A ХЛАДАГЕНТ ТРУБЫ СИСТЕМА ОХЛАЖДЕНИЯ

1

206-03-21151

HOSE

2

07299-00070

CLAMP, HOSE

3

20Y-03-41181

HOSE

4

21T-62-69711

CLAMP, HOSE

5

206-03-21621

TUBE

6

07000-E2065

O-RING

7

01010-81030

BOLT

8

01643-31032

WASHER

9

206-03-21651

BRACKET

10

01010-81230

BOLT

11

01643-31232

WASHER

12

07283-37060

CLIP, PIPE

13

01643-31032

WASHER

14

01597-01009

NUT

15

206-03-22141

HOSE

16

07289-00055

CLAMP, HOSE

17

206-03-21611

HOSE

18

07289-00055

CLAMP, HOSE

19

208-62-38370

CLIP

20

01010-81035

BOLT

21

01643-31032

WASHER

22

201-03-29160

SPACER

23

20Y-03-32660

STAY

24

01010-81635

BOLT

25

01643-31645

WASHER

26

20Y-03-41611

GUARD

27

01010-81025

BOLT

28

01643-31032

WASHER

29

20Y-03-41622

GUARD

30

20Y-03-41811

BRACKET

31

01010-81020

BOLT

32

01643-31032

WASHER

33

01010-81025

BOLT

34

01643-31032

WASHER

35

6738-11-4320

PIPE

36

07043-70108

PLUG

37

6738-11-4370

O-RING

38

6738-11-4380

CLAMP

39

6738-11-4390

NUT

40

20Y-03-41161

HOSE

41

21T-62-69711

CLAMP, HOSE

42

01010-81635

BOLT

43

21T-54-16150

WASHER

44

01010-81640

BOLT

45

01643-31645

WASHER

46

01010-81030

BOLT

47

01643-31032

WASHER

48

206-03-43340

CLIP

49

206-03-22371

SHEET

50

20Y-03-41831

SHEET

51

20Y-62-51481

BRACKET

52

01010-81225

BOLT

53

01643-31232

WASHER

54

206-03-22662

TUBE

55

206-03-22740

BRACKET

56

07283-37060

CLIP, PIPE

57

01643-31032

WASHER

58

01597-01009

NUT
