Запчасти Komatsu PC270LC-8 A9-AA ГЕНЕРАТОР V - AMP ДВИГАТЕЛЬ

Схема запчастей Komatsu PC270LC-8 - A9-AA ГЕНЕРАТОР V - AMP ДВИГАТЕЛЬ
21
20
19
5
3
7
6
1
2
4
30
18
13
17
14
28
22
27
23
10
29
25
12
17
15
16
11
24
9
26
8

Артикул

Название

Примечание

Количество

|$0

600-861-6420

ALTERNATOR ASSEMBLY

|$1

ND121400-0800

FRAME ASSEMBLY

1

ND021100-4210

STATOR ASSEMBLY

2

ND021401-4980

FRAME

3

ND021411-0570

PLATE

4

ND021045-0530

COLLAR

5

ND949006-5590

SCREW

6

ND949100-5010

BEARING, BALL

7

ND949043-2000

BOLT, STUD

8

ND021501-8050

FRAME, REAR

9

ND021580-4820

HOLDER

10

ND021620-2720

BRUSH HOLDER ASSEMBLY

11

ND126000-2320

BRUSH HOLDER ASSEMBLY

12

ND021551-2480

COVER

13

ND021605-1970

BUSHING

14

ND021605-2481

BUSHING

15

ND949006-5460

SCREW

16

ND91310-04251

SCREW

N/I

ND949007-5110

SCREW

17

ND949056-2481

NUT

18

ND949056-3080

NUT

19

ND021200-8380

ROTOR ASSEMBLY

20

ND949100-2790

BEARING, BALL

21

ND021506-0070

COVER

22

ND021041-8620

PULLEY

23

ND949056-2520

NUT

24

ND021626-0190

SEAL

25

ND021626-0250

SEAL

26

ND021542-0160

WASHER

27

ND949006-6401

SCREW

28

ND949007-6280

SCREW

29

ND021602-5230

PLATE

30

ND92150-06061

NUT

Выбрано товаров: 33
