Запчасти Komatsu PC270LC-8 T-A СТРЕЛА ПРАВ. ЦИЛИНДР РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0H930

CYLINDER ASSEMBLY, RH

1

707-13-14860

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL, DUST

4

707-58-10801

ROD, PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL, DUST

7

707-27-14690

CYLINDER HEAD

8

07179-13114

RING, SNAP

9

176-63-56170

SEAL, DUST

10

707-52-90780

BUSHING

11

707-75-10160

RING, SNAP

12

707-51-10030

PACKING

13

07000-15130

O-RING

14

707-35-91420

RING, BACK-UP

15

707-51-10650

RING

16

01010-81875

BOLT

17

707-41-11840

WASHER

18

707-36-14650

PISTON

19

707-44-14150

RING, PISTON

20

707-39-14110

RING, WEAR

21

707-44-14910

RING

22

707-71-71020

PLUNGER

23

07000-15090

O-RING

24

07001-05090

RING, BACK-UP

25

01310-01216

SCREW

26

707-71-35020

COLLAR

27

707-35-91420

RING, BACK-UP

28

07000-15130

O-RING

29

707-86-66200

TUBE

30

206-63-54680

TUBE

31

07372-21060

BOLT

32

01643-51032

WASHER

33

07372-21045

BOLT

34

01643-51032

WASHER

35

07000-13030

O-RING

36

707-88-28230

BRACKET

37

707-88-21321

BAND

38

07372-21035

BOLT

39

01643-51032

WASHER

40

07283-32738

CLIP, PIPE

41

01597-01009

NUT

42

01643-31032

WASHER

43

707-88-33030

CAP

44

07371-30640

FLANGE, SPLIT

45

07372-21035

BOLT

46

01643-31032

WASHER

|$47

707-99-59320

SERVICE KIT, BOOM CYLINDER
