Запчасти Komatsu PC270LC-8 K-A КАБИНА ПЕДАЛЬ - P & T БЛОКS ТРУБЫ OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

22U-54-25660

SEAL

2

20Y-43-41760

SEAT

3

01010-81025

BOLT

4

01643-31032

WASHER

5

01643-31032

WASHER

6

20Y-62-25360

BRACKET

7

01010-81035

BOLT

8

NSS

WASHER

9

207-43-81250

PEDAL

10

01010-81045

BOLT

11

NSS

WASHER

12

22U-54-25180

PLATE

13

01010-81020

BOLT

14

01643-31032

WASHER

15

207-43-81220

PEDAL

16

01240-00816

SCREW

17

207-43-81240

CAP

18

20T-910-8660

NIPPLE

19

07000-12011

O-RING

20

20Y-62-52160

ELBOW

21

02896-11008

O-RING

22

07000-12011

O-RING

23

20Y-62-43470

NIPPLE

24

02896-11008

O-RING

25

11Y-62-12140

NIPPLE

26

02896-11008

O-RING

27

07000-12011

O-RING

28

20Y-62-52340

HOSE, L = 4100 MM

29

20Y-62-52350

HOSE, L = 3350 MM

30

208-62-72310

HOSE, L = 950 MM

31

208-62-72650

HOSE, L = 1200 MM

32

20Y-62-22790

BAND, RED

33

20Y-62-22820

BAND, BLUE

34

20Y-62-22840

BAND, BLACK

35

20Y-62-22860

BAND, BROWN

36

08034-20519

BAND

37

04435-51210

CLIP

38

195-33-11220

SPACER

39

01010-81050

BOLT

40

01643-31032

WASHER

41

01583-11408

NUT

42

206-06-61130

SWITCH

43

20Y-53-14130

BRACKET

44

08034-20519

BAND
