Запчасти Komatsu PC270LC-8 H8-A ГИДРОЛИНИЯ MULTI-УПРАВЛЯЮЩ. КЛАПАН И КРЕПЛЕНИЕ (заводской номер A877- ) ГИДРАВЛИКА

1

20Y-62-A1532

VALVE, MULTI-CONTROL

2

01010-80875

BOLT

3

01643-30823

WASHER

4

20Y-62-A1540

HANDLE, MULTI-CONTROL

5

01010-80620

BOLT

6

01643-30623

WASHER

7

01640-20816

WASHER

8

203-62-59270

BOLT, WING

9

04050-12015

PIN, COTTER

10

20Y-62-22271

ELBOW

N/I

20Y-62-19560

O-RING

N/I

201-60-11390

O-RING

N/I

01583-51408

NUT

11

07002-11423

O-RING

12

20Y-62-22160

ADAPTER

13

07002-11423

O-RING

14

11Y-62-12240

ELBOW

15

02896-11008

O-RING

16

07002-11423

O-RING

17

11Y-62-12160

ELBOW

18

02896-11008

O-RING

19

07002-11423

O-RING

20

20Y-62-A1550

BRACKET, MULTI-CONTROL

21

01010-81235

BOLT

22

01643-31232

WASHER

23

20Y-62-51890

HOSE, L=900 MM, BLUE BAND, C1 PORT

24

208-62-72590

HOSE, L=700 MM,YELLOW BAND, A1 PORT

25

207-62-72720

HOSE, L=1400 MM, BROWN BAND, B2 PORT

26

20Y-62-42570

HOSE, L=1200 MM, GREEN BAND, D2 PORT

27

20Y-62-42580

HOSE, L=1350 MM,YELLOW BAND, A2 PORT

28

20Y-62-42580

HOSE, L=1350 MM, BLUE BAND, C2 PORT

29

208-62-72160

HOSE, L=720 MM,BROWN BAND, B1 PORT

30

208-62-72310

HOSE, L=950 MM,GREEN BAND, D1 PORT

N/I

208-62-72310

BAND, GREEN

N/I

208-62-72590

BAND, YELLOW

N/I

208-62-72160

BAND, BROWN

N/I

20Y-62-51890

BAND, BLUE
