Запчасти Komatsu PC270LC-8 H-A ГИДР. БАК. С ДОПОЛН. АКТУАТОР ГИДРАВЛИКА

1

20Y-60-41114

TANK

2

203-60-31100

ELBOW ASSEMBLY

3

203-60-31160

TUBE

4

07044-12412

PLUG, WITH MAGNET

5

07002-12434

O-RING

6

02781-00628

UNION

7

02896-11018

O-RING

8

07002-12434

O-RING

9

02782-10522

ELBOW

10

02896-11015

O-RING

11

07002-12434

O-RING

12

02782-10315

ELBOW

13

02896-11009

O-RING

14

07002-12034

O-RING

15

02782-10311

ELBOW

16

02896-11009

O-RING

17

07002-11423

O-RING

18

20Y-62-45690

TEE

19

02896-11009

O-RING

20

02896-11008

O-RING

21

07002-12034

O-RING

22

207-60-71182

ELEMENT

23

20Y-60-31140

STRAINER

24

20Y-60-31131

VALVE ASSEMBLY

25

20Y-60-21240

SPRING

26

22U-60-21232

COVER

27

07000-15195

O-RING

28

01010-81230

BOLT

29

01643-31232

WASHER

|$29

20Y-60-31171

STRAINER ASSEMBLY

30

207-60-61150

ROD ASSEMBLY

31

20Y-60-21320

HOLDER

32

12R-60-11230

SPRING

33

22B-60-11160

STRAINER

34

20Y-60-41212

COVER

35

07000-15160

O-RING

36

01010-81230

BOLT

37

01643-31232

WASHER

38

17A-60-11310

CAP ASSEMBLY

39

20Y-60-21470

ELEMENT

40

208-60-71180

NECK

41

20Y-60-21340

GASKET

42

01252-70516

BOLT, HEXAGON SOCKET HEAD

43

01601-20513

WASHER, SPRING

44

07285-00155

CLIP, HOSE

45

206-60-41240

TUBE

46

20Y-60-31270

BREATHER ASSEMBLY

47

207-60-51310

ELEMENT

48

207-60-51320

SEAL

49

01252-70516

BOLT, HEXAGON SOCKET HEAD

50

01601-20513

WASHER, SPRING

51

205-00-73360

PLATE, DECAL

52

01010-81635

BOLT

53

01643-31645

WASHER
