Запчасти Komatsu PC270LC-8 СОЛЕНОИДНЫЙ КЛАПАН ТРУБЫ, СОЛЕНОИДНЫЙ КЛАПАН (№7-) СОЛЕНОИДНЫЙ КЛАПАН ТРУБЫ, -АКТУАТОР

|$0

20Y-60-41611

Solenoid Assembly

1

Block

2

20Y-60-32121

Solenoid Assembly

3

07000-12016

O-ring

4

07000-12011

O-ring

5

NY05062-1170A

Plunger

6

NY05062-11800

Spring

7

NY06277-1320A

Plug

8

NY06339-10200

Spring

9

NY07207-11700

Tube

10

NY07493-10200

Spool

11

NY07529-10200

Tube

12

NY07529-10300

Tube

13

NY07529-10400

Tube

14

NY07529-10500

Tube

15

NY07529-10600

Tube

16

NY09000-11400

Plate

17

NY16207-10200

Sleeve

18

NY16207-10300

Spool

19

NY80000-02100

Plug

20

NY80000-02200

Plug

21

NY81416-05012

Bolt, Hexagon Socket Head

22

NY84110-00248

Screw

23

07000-11008

O-ring

24

07000-11010

O-ring

25

NY89103-00090

Band

26

20Y-62-16630

Nipple

27

201-60-11390

O-ring

28

20Y-62-19560

O-ring

29

20Y-62-41960

Tee

30

11Y-62-12130

Nipple

31

22B-26-11320

Union

32

02896-11008

O-ring

33

07002-11423

O-ring

34

02783-10315

Elbow

35

02896-11009

O-ring

36

07002-12034

O-ring

37

20Y-62-21940

Joint

38

07002-12034

O-ring

39

11Y-62-12130

Nipple

40

02896-11008

O-ring

41

07002-11423

O-ring

42

22U-60-21330

Accumulator

43

07002-12034

O-ring
