Запчасти Komatsu PC270LC-8 ЦИЛИНДР РУКОЯТИ(№7-) ЦИЛИНДР РУКОЯТИ, ЧАС. СМАЗКА INTERVAL

|$0

707-01-0H950

Cylinder Assembly

1

707-13-15280

Cylinder

2

707-58-11740

Rod, Piston

3

707-76-10290

Bushing

4

07145-00100

Seal, Dust, (Kit : K04)

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust, (Kit : K04)

7

07020-00000

Fitting, Grease

8

707-71-35030

Collar

9

707-35-91660

Ring, Back-up, (Kit : K04)

10

07000-15140

O-ring, (Kit : K04)

11

707-71-61140

Plunger

12

707-71-80280

Plunger

13

04260-00635

Ball, Steel

14

707-71-91270

Cap

15

707-27-15650

Head

16

707-56-11740

Seal, Dust, (Kit : K04)

17

07179-13126

Ring, Snap

18

707-51-11030

Packing, Rod, (Kit : K04)

19

707-51-11650

Ring, Buffer, (Kit : K04)

20

707-35-91660

Ring, Back-up, (Kit : K04)

21

07000-15140

O-ring, (Kit : K04)

22

707-52-90851

Bushing

23

707-75-11040

Ring, Snap

24

01010-82085

Bolt

25

707-88-75310

Washer

26

707-36-15260

Piston

27

707-44-15150

Ring, Piston, (Kit : K04)

28

707-39-15110

Ring, Wear, (Kit : K04)

29

707-44-15911

Ring

30

07001-05100

Ring, Back-up, (Kit : K04)

31

07000-15100

O-ring, (Kit : K04)

32

01310-01216

Screw

33

707-83-13010

Valve

34

07750-01628

Spring

35

707-87-14070

Plug

36

07002-12034

O-ring, (Kit : K04)

37

707-86-67920

Tube

38

20D-62-17860

Elbow

39

07372-21060

Bolt

40

01643-51032

Washer

41

07372-21045

Bolt

42

01643-51032

Washer

43

07000-13030

O-ring, (Kit : K04)

44

07000-13035

O-ring, (Kit : K04)

45

707-88-22670

Bracket

46

707-88-21351

Band

47

01010-81080

Bolt

48

01643-31032

Washer

49

707-88-36130

Plate

50

01643-31032

Washer

51

01597-01009

Nut

52

07283-32738

Clip, Pipe

53

07372-21035

Bolt

54

01643-51032

Washer

55

707-88-33030

Cap

56

07371-30640

Flange, Split

57

707-88-33040

Cap

58

07371-31049

Flange, Split
