Запчасти Komatsu PC270LC-7L ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ942

ARM CYLINDER GROUP,(FINAL COATING)

|$1

707-01-XZ942

ARM CYLINDER GROUP,(FINAL COATING)

|$2

707-01-XZ941

ARM CYLINDER GROUP,(FINAL COATING)

|$7

707-01-0Z942

CYLINDER ASS'Y

|$8

707-01-0Z941

CYLINDER ASS'Y,(FINAL COATING)

1

707-13-15240

CYLINDER

2

707-76-10310

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

707-58-11351

ROD,PISTON

5

707-76-80470

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-15610

HEAD,CYLINDER

8

07179-13126

RING,SNAP

9

198-63-94170

SEAL,DUST (KIT)

10

707-52-90850

BUSHING

11

707-51-11030

PACKING,ROD (KIT)

12

07000-15140

O-RING (KIT)

13

707-35-91660

RING,BACK-UP (KIT)

14

707-51-11640

RING,BUFFER (KIT)

15

01010-82085

BOLT

16

707-88-75310

WASHER

17

707-36-15260

PISTON

18

707-44-15180

RING,PISTON (KIT)

19

707-39-15110

RING,WEAR (KIT)

20

707-44-15911

RING

21

707-71-61130

PLUNGER

22

07000-15100

O-RING (KIT)

23

07001-05100

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

707-71-70290

PLUNGER

26

07020-00000

FITTING,GREASE

27

707-71-32850

COLLAR

28

707-35-91660

RING,BACK-UP (KIT)

29

07000-15140

O-RING (KIT)

30

04260-00635

BALL

31

707-71-91270

CAP

32

707-83-13010

VALVE

33

07750-01628

SPRING

34

707-87-14070

PLUG

35

07002-12034

O-RING (KIT)

36

707-86-66381

TUBE

|$46

707-86-66380

TUBE

37

20D-62-17860

ELBOW

38

01435-01055

BOLT

39

01435-01040

BOLT

40

07000-13030

O-RING (KIT)

41

01435-01075

BOLT

42

07000-13035

O-RING (KIT)

43

707-88-22670

BRACKET

44

707-88-21351

BAND

45

01435-01030

BOLT

46

707-88-36130

PLATE

|$57

707-88-11560

PLATE

47

07283-22738

CLIP

48

01599-01011

NUT

49

01643-31032

WASHER

50

707-88-33030

CAP,(FOR SHIPPING)

51

07371-30640

FLANGE,SPLIT (FOR SHIPPING)

52

707-88-33040

CAP,(FOR SHIPPING)

53

07371-31049

FLANGE,SPLIT (FOR SHIPPING)

54

07372-21035

BOLT,(FOR SHIPPING)

55

01643-51032

WASHER,(FOR SHIPPING)

|$68

707-99-59620

SERVICE KIT
