Запчасти Komatsu PC270LC-7L МЕХАНИЗМ ПОВОРОТА ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

206-26-73110

CASE

2

07029-00000

VALVE

3

206-26-73150

BEARING

4

206-26-73160

BEARING

5

206-26-73210

SHAFT

6

20Y-26-22420

SEAL

7

206-26-73140

SPACER

8

07000-15310

O-RING

9

206-26-71480

CARRIER

10

206-26-71440

GEAR

11

22U-26-21320

BEARING

12

206-26-71520

THRUST WASHER

13

206-26-71510

PIN

14

20Y-26-21330

PIN

15

20Y-26-21240

PLATE

16

112-32-11211

BOLT¤ SHOE

17

206-26-71452

GEAR

18

20K-22-11190

O-RING

19

01010-81440

BOLT

20

01643-31445

WASHER

21

206-26-71430

GEAR

22

04260-01270

BALL

23

206-26-71470

CARRIER

24

206-26-71420

GEAR

25

20Y-27-22210

BEARING

26

22U-26-21230

WASHER

27

206-26-71210

PIN

28

04064-03515

RING

29

206-26-71350

HOLDER

30

206-26-71410

GEAR

31

206-26-71341

PLATE

32

195-03-13241

VALVE

33

07270-21560

TUBE

34

07281-00197

CLAMP

35

01010-81035

BOLT

36

01643-51032

WASHER

37

22U-26-21280

RING

38

07043-00312

PLUG

39

706-7G-03040

MOTOR SUB ASS'Y,(SEE FIG.Y1640-01A0)

40

07000-15250

O-RING

41

01010-82070

BOLT

42

01643-32060

WASHER

43

206-26-71540

TUBE

44

20Y-26-31420

FILLER

45

20Y-26-31430

GAUGE

46

20Y-26-31441

BRACKET

47

22U-26-21460

CAP

48

07238-10630

CONNECTOR

49

07283-32738

CLIP

50

04434-51710

CLIP

51

01597-01009

NUT

52

01643-31032

WASHER

53

01010-81030

BOLT

54

01643-31032

WASHER

55

01010-81025

BOLT

56

01643-31032

WASHER
