Артикул
Название
Примечание
Количество
1
702-16-01230
PILOT VALVE,(SEE FIG. Y1670-21A0)
2
22U-54-25660
SEAL
3
22U-43-21470
SEAT
4
01010-81025
BOLT
5
01643-31032
WASHER
6
01643-31032
WASHER
7
20Y-62-25360
BRACKET
8
01010-D1025
BOLT
9
01643-71032
WASHER
10
20Y-43-31220
PEDAL
11
01010-D1045
BOLT
12
01643-71032
WASHER
13
22U-54-25541
PLATE
14
01010-81020
BOLT
15
01643-31032
WASHER
16
22U-54-25670
CAP
17
21W-62-43980
ELBOW
18
02896-11008
O-RING
19
07000-12011
O-RING
20
20Y-62-43470
NIPPLE
21
02896-11008
O-RING
22
11Y-62-12140
NIPPLE
23
02896-11008
O-RING
24
07000-12011
O-RING
25
02760-00212
HOSE¤ 1200MM
26
20Y-62-43490
HOSE¤ 2400MM
27
20Y-62-43510
HOSE¤ 2350MM
28
20Y-62-22790
BAND¤ RED
29
20Y-62-22810
BAND¤ YELLOW
30
20Y-62-22820
BAND¤ BLUE
31
08034-00519
BAND
32
21W-62-42240
HOSE
33
04435-51210
CLIP
34
01010-81016
BOLT
35
01643-31032
WASHER
36
01583-51408
NUT
37
702-21-07010
VALVE ASS'Y,EPC
38
203-60-62220
BOLT
39
700-93-11320
O-RING
40
07000-02011
O-RING
41
20Y-62-43410
BLOCK
42
01010-80820
BOLT
43
01643-30823
WASHER
44
20Y-62-43420
BRACKET
45
11Y-62-12160
ELBOW
46
02896-11008
O-RING
47
07002-11423
O-RING
48
21W-62-43960
ELBOW
49
02896-11008
O-RING
50
07002-11423
O-RING
51
08053-01510
CLIP
52
04434-51010
CLIP
53
20Y-62-22830
BAND¤ WHITE
54
20Y-62-43430
BLOCK,(SEE FIG. H1840-02A1)
Выбрано товаров: 54
