Запчасти Komatsu PC270LC-6LE FIG NO. A-AA ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ - SADE-

1

6736-51-8720

GASKET, OIL DRAIN

|$1

6731-81-8140

TURBOCHARGER ASSEMBLY

|$2

NSS

TURBOCHARGER

2

6736-81-8370

BEARING, TURBOCHARGER

3

6731-81-8160

NUT, LOCK

4

6733-81-8650

WASHER, PLAIN

5

6736-81-8480

SCREW, DRIVE

6

6736-81-8430

SHIELD, TURBOCHARGER HEAT

7

6736-81-8280

SHAFT AND WHEEL

8

6733-81-8360

RING, RETAINING

9

NSS

DATAPLATE

10

6733-81-8320

CONNECTION, ADAPTER

11

6733-81-8330

BAFFLE, OIL

12

6733-81-8340

END, ADJUSTING LINK

13

6733-81-8250

NUT, LOCK

14

6733-81-8370

RING, RETAINING

15

6733-81-8810

NUT, REGULAR

16

6733-81-8460

SEAL, O-RING

17

6733-81-8380

BOLT, M8-1.25 X 20

18

6733-81-8270

PLATE, OIL SEAL

19

6733-81-8260

SLINGER, OIL

20

NSS

ACTUATOR, TURBOCHARGER

21

6733-81-6850

SPACER, MOUNTING

22

6730-81-6810

SPACER, MOUNTING

23

6735-81-8610

BEARING, THRUST

24

6735-81-8620

COLLAR, THRUST

25

6735-81-8640

BOLT, M8-1.25 X 55

26

NSS

HOUSING, TURBINE

27

6733-81-8480

PIN, ROLL

28

6735-81-8510

HOUSING, BEARING

29

1304 920 H1

PLATE, CLAMPING

30

6733-81-8840

BOLT, M8-1.25 X 35

31

6735-81-8310

RING, RETAINING

32

6735-81-8490

BRACKET, ACTUATOR

33

6733-51-8110

GASKET, TURBOCHARGER

34

NSS

HOUSING, COMPRESSOR

35

NSS

IMPELLER, COMPRESSOR

36

6736-81-8440

SEAL, SPLIT RING

37

6736-81-8320

SEAL, SPLIT RING

38

6736-81-8380

BOLT, M8-1.25 X 12

39

6736-81-8360

RING, RETAINING

40

6736-11-5710

GASKET, TURBOCHARGER

41

6732-81-8820

NUT - M10-1.50

42

6732-81-8810

STUD - M10-1.50 BOTH ENDS X 42
