Запчасти Komatsu PC270LC-6LE FIG NO. A-AA STARTER - VOLT, . KIНИЗ.ATT ТИП R NIPPON DENSO 8- ДВИГАТЕЛЬ - SADE-
№
Артикул
Название
Примечание
Количество
|$0
6736-81-4210
MOTOR, STARTER - PRODUCTION ONLY
|$1
1310 443 H91
MOTOR, STARTER - SERVICE
1
1308 948 H1
ASSEMBLY, STARTER YOKE
2
1308 949 H91
ASSEMBLY, STARTER ARMATURE
3
1308 950 H1
BEARING, BALL - 35 MM OD
4
1308 951 H1
BEARING, BALL - 35 MM OD
5
1308 952 H1
BEARING, BALL - 30 MM OD
|$7
1308 862 H91
SUB-ASSEMBLY, STARTER CLUTCH
6
1308 863 H1
KIT, STARTER PINION
7
1308 953 H91
KIT, STARTER CLUTCH SUB-ASSEMBLY
8
1308 865 H1
BEARING, FRONT BALL
9
1308 864 H1
BEARING, REAR BALL
10
1308 866 H1
SPRING, COMPRESSION COIL
11
1308 867 H1
SHAFT
12
1308 954 H1
HOUSING, STARTER
13
1308 955 H91
ASSEMBLY, MAGNETIC SWITCH
14
1308 956 H1
KIT, STARTER TERMINAL - KIT M
15
1308 957 H1
KIT, STARTER TERMINAL - KIT C
16
1308 958 H1
SUB-ASSEMBLY, PLUNGER
17
1308 872 H1
GASKET, SWITCH A
18
1308 873 H1
COVER, SOLENOID
19
1308 959 H1
SUB-ASSEMBLY, TERMINAL BOLT
20
1308 960 H1
BOLT - WITH WASHER
21
1308 875 H1
BUSHING, DRAIN
22
1308 961 H91
ASSEMBLY, STARTER BRUSH HOLDER
23
1308 962 H1
SPRING, BRUSH
24
1308 963 H1
FRAME, STARTER END
25
1308 879 H1
BALL, STEEL
26
1308 880 H1
SPRING, COMPRESSION COIL
27
1308 964 H1
PINION, STARTER
28
1308 882 H1
ROLLER, CLUTCH
29
1308 883 H1
RETAINER
30
1308 855 H1
COVER
31
1308 965 H1
BOLT, THRU - M7 X L144.5
32
1308 966 H1
BOLT, THRU - M7 X L206
33
1308 890 H1
SCREW - M6 X L50
34
1308 893 H1
NUT, HEX - M10 X L6
35
1308 884 H1
RETAINER, SNAP
36
1308 894 H1
WASHER, SPRING - M10
37
1308 967 H1
SEAL, STARTER
38
1308 968 H1
PINION, STARTER
39
1308 889 H1
SCREW - WITH WASHER - M5 X L9.4
40
1308 969 H1
SUB-ASSEMBLY, STARTER BRUSH
41
1308 970 H1
SUB-ASSEMBLY, STARTER BRUSH
42
1308 892 H1
SCREW - WITH WASHER - M5 X L8
43
1308 895 H1
COVER
44
1308 898 H1
NUT - M10
45
1308 971 H1
O-RING - 47.2 MM ID
46
1308 897 H1
WASHER, PLATE - T1
47
1308 891 H1
O-RING - 4.8 MM ID
