Запчасти Komatsu PC270LC-6LE FIG NO. T- ЦИЛИНДР РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

206-63-03370

CYLINDER ASSEMBLY, ARM

1

206-63-64540

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL, DUST

4

206-63-64520

ROD, PISTON

5

707-27-15710

HEAD, CYLINDER

6

07179-13126

RING, SNAP

7

198-63-94170

SEAL, DUST

8

707-52-90850

BUSHING

9

707-51-11030

PACKING, ROD

10

07000-15160

O-RING

11

707-35-91660

RING, BACK-UP

12

707-51-11630

RING, BUFFER

13

01010-82090

BOLT

14

707-88-75310

WASHER

15

707-36-15360

PISTON

16

707-44-15180

RING, PISTON

17

707-39-15820

RING, WEAR

18

707-44-15911

RING

19

01310-01216

SCREW

20

707-71-61111

PLUNGER

21

707-71-60250

PLUNGER

22

07020-00900

FITTING

23

707-71-32850

COLLAR

24

707-35-91660

RING, BACK-UP

25

07000-15160

O-RING

26

04260-00635

BALL

27

707-71-91270

CAP

28

07000-15100

O-RING

29

07001-05100

RING, BACK-UP

30

707-76-10130

BUSHING

31

07145-00100

SEAL, DUST

32

01435-01040

BOLT

33

01435-01055

BOLT

34

07000-13030

O-RING

35

01010-81080

BOLT

36

01643-31032

WASHER

37

07000-13035

O-RING

38

707-88-21220

BRACKET

39

707-88-22310

BAND

40

01010-81035

BOLT

41

01643-51032

WASHER

42

707-88-11560

PLATE

43

07283-22738

CLIP

44

01599-01011

NUT

45

01643-31032

WASHER

46

707-83-13010

VALVE

47

07750-01628

SPRING

48

707-87-14070

PLUG

49

07002-12034

O-RING

50

206-63-64570

TUBE

51

20D-62-17860

ELBOW

|$52

707-99-59600

SERVICE KIT, ARM CYLINDER
