Запчасти Komatsu PC270LC-6LE FIG NO. M-A ЛЕВ. ДВЕРЬ КАБИНА - СТАНДАРТН. DUTY ЧАСТИ КОРПУСА

|$0

206-54-A1300

DOOR ASSEMBLY, L.H

1

20Y-54-28114

COVER - S/N A83001-A83110

2

20Y-54-28161

HINGE - S/N A83001-A83110

3

20Y-54-28281

SHEET - S/N A83001-A83110

4

01010-81225

BOLT - S/N A83001-A83110

|$5

206-54-A1301

DOOR ASSEMBLY, L.H

1

20Y-54-28115

COVER - S/N A83111-A85000

2

203-54-62180

HINGE - S/N A83111-A85000

3

20Y-54-28281

SHEET - S/N A83111-A85000

4

01010-81235

BOLT - S/N A83111-A85000

|$10

206-54-A1303

DOOR ASSEMBLY, L.H

1

206-54-A1380

COVER - S/N A85001 AND UP

2

20Y-54-28161

HINGE - S/N A85001 AND UP

3

20Y-54-28281

SHEET - S/N A85001 AND UP

4

01010-81230

BOLT - S/N A85001 AND UP

5

01643-31232

WASHER

|$16

206-54-A1310

COVER ASSEMBLY - S/N A83001-A83110

6

206-54-A1320

COVER - S/N A83001-A83110

7

20Y-54-28161

HINGE - S/N A83001-A83110

|$19

206-54-A1311

COVER ASSEMBLY - S/N A83111-A85000

6

206-54-A1321

COVER - S/N A83111-A85000

7

203-54-62180

HINGE - S/N A83111-A85000

|$22

206-54-A1312

COVER ASSEMBLY - S/N A85001 AND UP

6

206-54-A1322

COVER - S/N A85001 AND UP

7

207-54-61870

HINGE - S/N A85001 AND UP

8

198-54-41982

LOCK ASSEMBLY - S/N A83001 AND UP

9

20Y-54-28191

SHEET - S/N A83001 AND UP

10

205-54-53550

DOVE TAIL

11

01010-80612

BOLT

12

01643-30623

WASHER

13

01010-81235

BOLT

14

01643-31232

WASHER

15

20Y-54-28290

PLATE - S/N A83001-A83110

15

20Y-54-28291

PLATE - S/N A83111-A85000

16

20Y-54-25311

FRAME

17

20Y-54-28170

BRACKET

18

01010-81230

BOLT

19

01643-31232

WASHER

20

205-54-51970

DOVE TAIL

21

01010-80616

BOLT

22

01643-30623

WASHER

23

20Y-54-28182

PLATE

24

01010-81230

BOLT

25

01643-31232

WASHER

26

20Y-54-29232

BAR

27

20Y-54-29232

BAR

N/I

20Y-54-29241

SEAL

N/I

20Y-54-29251

SEAL

N/I

20Y-54-29261

SEAL

28

20Y-54-27341

BRACKET

29

01010-81230

BOLT

30

01643-31232

WASHER

31

20Y-54-12920

CLAMP

32

01010-81025

BOLT

33

01643-31032

WASHER

34

20Y-54-11611

STOPPER

35

01580-11008

NUT

36

20Y-54-25351

FRAME

37

20Y-54-29271

SHEET

38

20Y-54-25361

FRAME

39

20Y-54-28390

PLATE - S/N A83111 AND UP
