Запчасти Komatsu PC270LC-6LE FIG NO. K-A КЛАПАН PPCХОД КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

702-16-01542

PILOT VALVE

1

NSS

BODY, VALVE

2

NSS

VALVE

3

702-16-51140

SHIM - 0.012 IN. (0.30 MM)

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-51270

SEAL

9

07000-12020

O-RING

10

702-16-54170

COLLAR

11

702-16-54311

CASE

12

NSS

LEVER

13

NSS

SHAFT

14

NSS

PLATE

15

01010-80855

BOLT

16

01643-30823

WASHER

17

01010-80816

BOLT

18

702-16-54331

WASHER - 0.063 IN. (1.60 MM)

19

04025-00432

PIN, SPRING

20

702-16-54430

BUSHING

21

702-16-54341

WASHER - 0.051 IN. (1.30 MM)

22

702-16-54351

WASHER - 0.039 IN. (1.00 MM)

23

702-16-54280

SEAL, DUST

24

702-16-54506

DAMPER ASSEMBLY

25

01252-60525

BOLT

26

702-16-54511

PLATE

27

04025-00420

PIN, SPRING

28

NSS

LEVER

29

01224-40612

SCREW

30

NSS

PLUG

31

NSS

PLUG

32

07040-11209

PLUG

33

07002-11223

O-RING

34

700-84-11730

BALL

35

702-16-55940

PLUG

36

702-16-55950

SEAT

37

04022-04016

PIN, DOWEL

38

04022-04010

PIN, DOWEL
