Запчасти Komatsu PC270LC-6LE FIG NO. A-AA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ - SADE-

Схема запчастей Komatsu PC270LC-6LE - FIG NO. A-AA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ - SADE-
24
23
22
17
10
5
13
1
12
19
8
16
2
7
9
14
4
15
4
3
11
6
18
20
21

Артикул

Название

Примечание

Количество

|$0

6731-11-1430

HEAD ASSEMBLY, CYLINDER

1

6731-11-1270

HEAD, CYLINDER

2

6736-11-1160

PLUG, EXPANSION

3

6732-11-1930

PLUG, PIPE - 1/8 IN. NPT

4

6732-11-1910

PLUG, PIPE - 1/2 IN. NPT

|$5

6736-41-4110

VALVE, INTAKE

5

6732-41-4520

COLLET, VALVE

6

NSS

VALVE, INTAKE

7

6732-41-4430

SPRING, INTAKE VALVE

8

6731-41-4510

RETAINER, INTAKE VALVE SPRING

9

6732-41-4540

SEAL, INTAKE VALVE STEM

|$11

6736-41-4210

VALVE, EXHAUST

10

6732-41-4520

COLLET, VALVE

11

NSS

VALVE, EXHAUST

12

6732-41-4430

SPRING, EXHAUST VALVE

13

6731-41-4510

RETAINER, EXHAUST VALVE SPRING

14

6732-41-4540

SEAL, EXHAUST VALVE STEM

15

6732-11-1920

PLUG, PIPE - 3/4 IN. NPT

16

6732-11-1610

BOLT - M12-1.75 X 70

17

6732-11-1620

BOLT - M12-1.75 X 120

18

6735-11-1821

GASKET, CYLINDER HEAD

19

6736-11-6110

TUBE, AFTERCOOLER

20

6736-19-1440

INSERT, VALVE - EXHAUST

21

6736-19-1430

INSERT, VALVE - INTAKE

22

6736-19-1310

GUIDE, VALVE STEM - INTAKE

23

6736-19-1410

GUIDE, VALVE STEM - EXHAUST

24

6736-18-1310

GUIDE, VALVE STEM - INTAKE/EXHAUST

Выбрано товаров: 27
